I. Introduction
1. Application
● Fiber lasers for cladding, welding and cutting
● Fiber lasers for marking and 3D printing
2. Functions and Features
● Circulating pump made from stainless steel features large flow, high head, low noise and long service life. Besides, such components as water tank, pipeline and cooling valves are also made from stainless steel.
● LCD controller is utilized for real-time display of cooling water temperature. Full-automatic CPU can realize man-machine interaction, making it visual and easy-to-operate. Water temperature control accuracy can achieve±1̊C. In addition, the controller featuring automatic fault diagnosis can display fault points on the screen, hence reminding the user of rapid processing.
● RS485 communication interface can be added to implement communication function.
● It serves multiple functions with passive alarm and remote control terminals, making it easy to realize integral control and monitoring of CNC system.
● Dual-temp water chillers can cool the main circuit and external optic circuit simultaneously, which are the optimal choice for lasers.
3. Model Description
TFLW ─ 500W D R ─ 01 V ─ 1225
(1) (2) (3) (4) (5) (6) (7)
(1) Product series: TFLW: Water chiller for fiber laser
(2) Fiber laser power: 500W: Fiber laser power is 500W
(3) Structure: D: dual-temp (In case of single-temp chiller, there is no letter)
(4) Additional functions: R: With heating function (Without heating function, there is no “R”.)
(5) Design serial number: there is a need for modification in case of great structural changes
(6) Special requirements: Be omitted for no special requirements E: With flow switch on main circuit
(7) Power supply: The first digit: phase The second/third digits: the first two figures of voltage The forth digit: frequency 1225: AC 1P 220V/50Hz
Notes:
1. Cooling capacity is measured at ambient temperature 35℃ and water outlet temperature 20℃.
2.Contact us for customized solutions.
